Precision Lighting Stacko Tilt Fixed End
Stacko Tilt Fixed End is a 3.4W miniature display orientated LED lighting module offering 4 beam distributions that is a part of the modular Stacko Collection which allows users to ‘stack’ lighting modules together to create unique lighting set-ups that comes as standard in white, black and brushed aluminium finishes. Stacko Tilt Fixed End is also available in 4 premium finishes and custom RAL. It is an ‘End’ Stacko lighting module which means it closes a circuit and does not accept other Stacko lighting modules above it. It has a total of 3 light engines with a combined output of 306lm. Each 102lm light engine produces a Narrow beam with a peak intensity of 794 cd. It has a fixed tilt angle of 35 degrees. Stacko Tilt Fixed End is infinitely adjustable in 360 degree pan. The luminaire is compatible with our Minipoint system that enables a plug and play setup where luminaires can be simply swapped to suit changing lighting requirements. Please note that there can only be maximum 10 light engines per Stacko circuit or driver.
See specification for more information or click here
