General

• Application: Indoor
• Product Category: Linear System
• Type: Ring
• Mounting Type: Pendant Wire Mounted
• Housing Color: Black, White
• Diffuser: Microprismatic
• IP: 20
• DIY: D600, D900, D1200

LED

• CCT: 3000K, 4000K|
• CRI: 80, 90
• LED Output: ≤10220lm
• System Output: ≤7423lm
• Lifetime: 50000h@L80B10
• LED Chip: SMD

Optics

• Beam Angle: 95°


Electric

• LED Driver: DALI Dim, ON-OFF
• LED Power: 25W, 35W, 52W
• System Power: 28W, 38W, 55W
• LED Voltage: 33V
• LED Current: 750mA, 1050mA, 1500mA
• Input Voltage: 220-240V(standard), 120V(option)

Dimensions

• Measurements: Ø660mm, Ø960mm, Ø1260mm
• Net Weight: 4200g, 6300g, 8400g
• Gross Weight: 4840g, 7260g, 9680g
