General

• Application: Indoor
• Product Category: Downlight
• Type: Adjustable
• Mounting Type: Recessed Mounted
• Trim: Square, Trimless Square, Trimless Square (Easy Installation)
• Housing Color: Black, White
• Reflector Color: Black, Dark Light, Gold, Matt, Specular, White
• IP: 20 - (LED Module IP 54)



LED

• CCT: 2700K, 3000K, 4000K
• CRI: 90
• LED Output: ≤1600lm
• System Output: ≤1250lm
• Lifetime: 50000h@L90B10
• Standard Deviation: SDCM: 2
• LED Chip: BRIDGELUX

Optics

• Beam Angle: 24°, 36°, 50°
• UGR: <19
• Optional Accessories: Honeycomb

Electric

• LED Driver: None, 0-10V Dim, DALI Dim, ON-OFF, Phase Dim
• LED Power: 9W, 13W
• System Power: 11W, 15W
• LED Voltage: 34V
• LED Current: 250mA, 350mA

Dimensions

• Measurements: 71mm x 71mm, 85mm x 85mm
• Cutout: 75mm x 75mm, 80mm x 80mm
• Ceiling Height: 150mm
• Pivot: 30°
• Rotation: 355°
