General

• Application: Indoor
• Product Category: Downlight
• Type: Adjustable
• Mounting Type: Recessed Mounted
• Trim: Round, Trimless Round (Easy Installation)
• Housing Color: Black, White
• Reflector Color: Black, Dark Light, Gold, Matt, Specular, White
• IP: 20 - (LED Module IP 54)

LED

• CCT: 2700K, 3000K, 4000K
• CRI: 90
• LED Output: ≤1400lm
• System Output: ≤880lm
• Lifetime: 50000h@L90B10
• Standard Deviation: SDCM: 2
• LED Chip: BRIDGELUX

Optics

• Beam Angle: 24°, 36°, 45°UGR: <19
• Optional Accessories: Honeycomb

Electric

• LED Driver: None, 0-10V Dim, DALI Dim, ON-OFF, Phase Dim
• LED Power: 10W
• System Power: 12W
• LED Voltage: 34V
• LED Current: 300mA
• Input Voltage: 220-240V(standard), 120V(option)

Dimensions

• Measurements: Ø53mm, Ø61mm
• Cutout: Ø55mm, Ø60mm
• Ceiling Height: 146mm
• Pivot: 30°
• Rotation: 355°
