Downloads : technical modifications reserved

sp-str9-ig-color-changing (pdf)

GVA lighting STR9® INGROUND COLOR CHANGING

An extremely reliable inground luminaire with a full glass top and an outstanding glare control system.

Key features

  • Up to 2040 lumens/meter (626 lumens/foot)
  • COLOR-AMP® technology allows up to three times higher light output in specific colors
  •   Outstanding color mixing (no striations or colour separation)
  •  Homogenous light output immediately adjacent to luminaire
  • Color match with FL Series
  •  Trimless inground luminaire, stainless steel top frame and aluminum body for improved thermal performance
  • Compact size, 77 mm (3.03 in) wide, 108mm (4.2 in) high
  •  IP68 rated luminaire with proprietary sealing process and solid extruded, anodized aluminum UNIBODY™ design
  • Electronic micro leak detection test performed for each hermetically sealed fixture
  •  Meets 3G ANSI C136.31-2010 Vibration Standard for Bridge and Overpass Applications
  • IK10 with 10mm optically clear tempered glass lens (no yellowing over time)
  • Through wiring for end-to-end connection via snap-in and lock connectors


Specifications

  • DELIVERED LUMENS:2040lm/m
  • INPUT VOLTAGE: AC 120 or 277 VAC and 220-240 VAC
  • LENGTH: 600mm (2ft), 900mm (3ft), 1200mm (4ft) and 1500mm (5ft)
  • CONTROL: DMX
  • ENVIRONMENT: Dry, Damp or Wet Locations

See specification for more information or click here
