Color changing linear wall washing and grazing exterior led lighting

• Up to 2,040 Delivered Lumens /m (626 lm/ft)
• 3 Voltage Options: AC Line voltage, ELV 48VDC, INFINITY® 380VDC
• LED Pitch Maintained Within and Between Luminaires
• Optically Clear Tempered Glass Lens
• Versatile Mounting Slot for Array of Mounting Options
• 300 mm (1 ft) Addressability
• Compact and Lightweight
• INFINITY® Technology enables exceptionally long lighting circuits
• Color Match with FL Series RGBW-IM
• UNIBODY™ Technology for industry-leading proprietary sealing against water ingress
• Color-mixing inside the optics and diffusing film creates uniform light adjacent to the luminaire
• Excellent LED to LED color consistency
• Through-wiring for end-to-end connection and plug-and-play with FL Series
• RGBA, RGB, or RGBW30K LED color combinations
• COLOR-AMP® Technology allows up to 3x higher light output

Specifications:

• Delivered lumens: 2,040 lm/m (626 lm/ft)
• Light source: 4 x high power 4-in-1 leds /300 mm (1 ft)
• Power: 10w, 15w or 20w /300 mm (1 ft)
• Input voltage: elv (48vdc), ac (120vac, 277vac, or 220~240vac), or inf (380vdc)
• Size (wxh): 71 x 63 mm (2.8 x 2.5 in)
• Length: 300, 343, 600, 900, 1200, or 1500 mm (1, 2, 3, 4, or 5 ft)
• Weight: 1.0 kg/ 300 mm (2.2 lbs/ 1ft)
• Addressability: 300 mm (1 ft)
• Control: dmx (via gva power-data equipment)
• Projected lifetime: l70 > 65,000hrs @ ta = 50°c (122°f)
• Operating temperature: -40°c to +50°c (-40°f to +122°f)
• Environment: dry, damp or wet locations, 0-100% humidity
• Iec class: class 1 led luminaire




See specification for more information or click here
